QUARTZ FILTER

SAND AND GRAVEL



Site of surface excavation of quartz sand and gravel



Separation and drying of quartz sand



Quartz filter sand



Eksploataciono polje Palez

Exploitation field



The stock company Kaolin is specialized in manufacturing quartz filter sand, gravel and implementing into the stations for cleaning water.

We manufacture all granulation types of quartz filter sand and gravel from 0 to 100mm, according to the customer's demands.



WET GRAVEL AND SAND

I For Well Water:

  1. 1,00 – 3,00 mm,
  2. 0,80 – 2,00 mm.....

II For waterworks/purification plants

SAND

  1. 0,60 – 1,40 mm,
  2. 0,80 – 1,20 mm.......

GRAVEL

  1. 2,00 – 5,00 mm,
  2. 5,00 – 8,00 mm,
  3. 8,00 – 15 mm,
  4. 15,00 – 25,00 mm......



DRIED GRAVEL AND SAND

 I Sandblasting:

  1. 1,00 – 3,00 mm,
  2. 0,50 – 2,00 mm,
  3. 0,30 – 1,20 mm,
  4. 0,40 – 0,80 mm......

II Construction:

  1. 0,00 – 0,50 mm,
  2. 1,40 – 2,00 mm,
  3. 0,10 – 3,20 mm,
  4. 0,30 – 1,20 mm,
  5. 0,00 – 2,00 mm......



CHEMICAL COMPOSITION

SiO2, %

98,07 – 98,60

Al2O3, %

0,3 – 0,6

Fe2O3, %

0,20 – 0,5

CaO, %

MAX 0,40

MgO, %

MAX 0,15

S, %

-

Na2O, %

MAX 0,15

K2O, %

MAX 0,20

CO2, %

MAX 0,10

LOSS OF IGNITION, %

< 0,5

MOISTURE OF WET SAND, %

< 0,6

MOHS SCALE

7
